Two-row cutting and silage workflow
A 1600 mm working width and two-row format support cutting, chopping and direct receiving-vehicle loading.
Product Description
Overview
The TAGRM 9QS1600 is a two-row, wheel-type self-propelled forage harvester for corn-stalk silage. It combines cutting and crop transport with flattening, chopping, throwing and loading into a receiving vehicle.
Its working width is 1600 mm, engine power is 102 kW and operating speed range is 3–6 km/h. The short machine layout is intended for smaller field layouts, with site access and terrain suitability assessed for the actual job.
Product Attributes
- Brand
- TAGRM
- Model
- 9QS1600
Performance Highlights
Adjustable cutting and discharge
Multi-level chopping adjustment and hydraulic throwing-direction, distance and stubble-height settings help match the crop and collection workflow.
Rotating discharge spout
The worm-gear mechanism provides 360° spout rotation and holds the selected discharge angle.
Compact field arrangement
Review the 5200 × 1890 × 3410 mm dimensions, turning space and optional cab before selecting the machine.
Product Categories
Product Overview
The round-disc drum-type cutting arrangement has adjustable chopping settings. A worm-gear mechanism turns the discharge spout through 360° and holds its direction. Hydraulic adjustment is described for throwing direction, throwing distance and stubble height. A cab is an option to confirm for the ordered configuration.
Technical Specifications
| Harvesting rows | 2 | Working width | 1600 mm |
|---|---|---|---|
| Engine power | 102 kW | Overall dimensions | 5200 × 1890 × 3410 mm |
| Drive arrangement | Wheel type | Cutting arrangement | Round-disc drum type |
| Operating speed | 3–6 km/h | Machine weight | 2800 kg |
Working Condition
Provide corn maturity, stalk condition, row spacing, required chop length and receiving-vehicle height and position. Check soil bearing condition, field access, turns and terrain with the supplier. Confirm cutter, spout and hydraulic operating instructions, routine inspection points and the optional cab in the quotation.
Frequently Asked Questions
How does the 9QS1600 transfer chopped forage?
Its discharge spout can rotate through 360° using a worm-gear mechanism. Match the discharge arrangement to the receiving vehicle and operating route.
Can chopping and stubble settings be adjusted?
Multi-level chopping adjustment is described, together with hydraulic settings for throwing direction, throwing distance and stubble height. Confirm the available setting ranges for the supplied unit.
Is a cab included?
A cab is described as optional. Identify the required operator arrangement explicitly in the quotation.
