Double-disc header
The header is described for tall and short-stem crop applications; confirm the actual crop and required output with the supplier.
Product Description
Overview
The TAGRM 9QS2000 is a two-row forage harvester with a double-disc header, a 2020 mm working width and a 118 kW engine-power specification. A 2.2 m³ loading tank supports the collection stage of the harvesting workflow.
The header is described for tall-stalk crops such as corn and sorghum, and shorter crops such as wheat and oats. Confirm the intended crop, maturity, cutting setup and forage output before ordering.
Product Attributes
- Brand
- TAGRM
- Model
- 9QS2000
Performance Highlights
2020 mm working width
A 2020 mm working width is specified for this two-row harvesting configuration.
Cutting-table adjustment
A 50–440 mm lift range and ≤100 mm minimum cutting height support field-setting review.
2.2 m³ collection tank
Coordinate the collection tank with the unloading cycle and receiving transport.
Product Categories
Product Overview
The cutting-table lift range is 50–440 mm and minimum cutting height is specified as no more than 100 mm. Overall dimensions are 5200 × 2230 × 4230 mm, with a listed machine weight of 3200 kg. Plan tank use, unloading and transport access as part of the field workflow.
Technical Specifications
| Harvesting rows | 2 | Working width | 2020 mm |
|---|---|---|---|
| Minimum cutting height | ≤100 mm | Cutting-table lift range | 50–440 mm |
| Engine power | 118 kW | Overall dimensions | 5200 × 2230 × 4230 mm |
| Machine weight | 3200 kg | Loading tank volume | 2.2 m³ |
Working Condition
Identify the crop and maturity, row layout, field surface, target cutting result and collection workflow. Confirm cutter setup, tank unloading, receiving access and the required operating and maintenance instructions. Assess engine and header compatibility for the supplied unit rather than assuming another 9QS model has the same equipment.
Frequently Asked Questions
Is the 9QS2000 working width 2000 mm?
The working-width specification is 2020 mm. The model number should not be used to infer a different width.
Which crops are described for the header?
Corn and sorghum are described as tall-stalk applications, with wheat and oats as shorter-stem applications. Confirm the crop, maturity and cutting setup for the intended forage operation.
How is harvested material collected?
The specification lists a 2.2 m³ loading tank. Confirm the unloading arrangement and receiving transport for the project.
